Features

F300/F3000 series Gateway are Residential Gateway equipped with 4/8 FXS,FXO, FXS+PSTN ports, two 10/100BaseTX Fast Ethernet WAN Port, and two 10/100BaseTX Fast Ethernet LAN Ports. With the integration of both voice and data, the F300/F3000 series offer ability to route data information into network solution. In addition to standard NAT router function services, end-users are enabled with low-cost long-distance calling by using Voice over IP technology.

The F300/F3000 series Gateway have voice support that include Quality of Service (QoS), voice compression, echo cancellation, dynamic latency (jitter) buffers, silence suppression, and comfort noise generation.

Key Features

• 4FXS/8FXS, 4FXS+4FXS/4FXS+4PSTN, 8FXS+8FXO/8FXS+8PSTN
• Support 4/8/16 simultaneous VoIP Calls
• 2LAN and 2 WAN Port
• Support QoS for VoIP, Bandwidth Control (Traffic shaping)
• Support SIP VoIP standard protocol
• When the power off, the phone set on FXS will call out from PSTN automatically (only in F3400&F3800)
• The phone set on FXS accept both PSTN and VoIP calls(only in F3400&F3800)
• IP's configuration of WAN / LAN can be programmed via phone sets.
• Support register up to 4 SIP servers
• Support APS (Auto Provision Server)
• Support Multiple dialing plan / Call hunting group
• Support SNMP, SNTP, HTTP, NAT ,uPnP, TFTP
• User friendly Web GUI
