4/8 Port VoIP Gateway
description DM-1 description DM-2Model | Description |
H340S | 4FXS, 1WAN, 1LAN |
H380S | 8FXS, 1WAN, 1LAN |
H304 | 4FXO,2WAN,2LAN |
H308 | 8FXO,2WAN,2LAN |
H3400 | 4FXS+4PSTN/2FXS+2FXO/4FXS/4FXO,2WAN.2LAN |
H3800 | 8FXS+8PSTN/4FXS+4FXO/8FXS/8FXO,2WAN,2LAN |
Features
H300/3000 series Gateway are Residential Gateway equipped with 4/8 FXS,FXO, FXS+PSTN ports, two 10/100BaseTX Fast Ethernet WAN Port, and two 10/100BaseTX Fast Ethernet LAN Ports. With the integration of both voice and data, the H300/3000 series offer ability to route data information into network solution. In addition to standard NAT router function services, end-users are enabled with low-cost long-distance calling by using Voice over IP technology.
The H300/3000 series Gateway have voice support that include Quality of Service (QoS), voice compression, echo cancellation, dynamic latency (jitter) buffers, silence suppression, and comfort noise generation.
Key Features
- 4/8 FXS,FXO,FXS+PSTN ports
- Support 4/8 simultaneous VoIP Calls
- 2LAN and 2 WAN Port
- Support QoS for VoIP, Bandwidth Control (Traffic shaping)
- Support SIP VoIP standard protocol
- When the power off, the phone set on FXS will call out from PSTN automatically (only in H3400&H3800)
- The phone set on FXS accept both PSTN and VoIP calls(only in H3400&H3800)
- IP's configuration of WAN / LAN can be programmed via phone sets.
- Support register up to 4 SIP servers
- Support APS (Auto Provision Server)
- Support Multiple dialing plan / Call hunting group
- Support SNMP, SNTP, HTTP, NAT ,uPnP, TFTP
- User friendly Web GUI
